Smart-UPS On-Line Features & Benefits
Availability
- Hot-swappable batteries: Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
- Automatic restart of loads after UPS shutdown: Automatically starts up the connected equipment upon the return of utility power.
- Scalable runtime: Allows additional run time to be quickly added as needed.
- Intelligent battery management: Maximises battery performance, life, and reliability through intelligent, precision charging.
- Automatic internal bypass: Supplies utility power to the connected loads in the event of a UPS power overload or fault.
- Temperature-compensated battery charging: Prolongs battery life by regulating the charge voltage according to battery temperature.
Manageability
- Network manageable: Most models provide remote power management options of the UPS over the network. Many do not have NMC embedded.
- LED status indicators: Quickly understand unit and power status with visual indicators.
- SmartSlot: Customise UPS capabilities with management cards.
- Serial connectivity: Provides management of the UPS via a serial port.
- InfraStruXure Manager Compatible: Enables centralised management via the APC InfraStruXure Manager.
Adaptability
- Flash upgradeable firmware: Install maintenance releases of firmware remotely using FTP.
- Rack/Tower convertible: Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
- Plug-and-Play external batteries: Ensures clean, uninterrupted power to the loads when adding extra runtime to the UPS.
Serviceability
- Audible alarms: Provides notification of changing utility power and UPS power conditions
- Disconnected battery notification: Warns when a battery is not available to provide backup power.
- Automatic self-test: Periodic battery self-test ensures early detection of a battery that needs to be replaced.
- User-replaceable batteries: Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
- Predictive failure notification: Provides early-warning fault analysis, ensuring proactive component replacement.
Marketing features
- Avoids costly power problems by keeping your IT equipment and data protected and available: Network grade power conditioning protects from damaging surges and disruptive noise. The double conversion architecture provides tight voltage regulation, frequency regulation ,and zero transfer time to the battery during power events.
- Peace of mind that comes with full equipment compatibility and reliability of a leader: Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that it meets or exceeds the industry s most rigorous standards.
- Low operating and maintenance costs with proven reliability and intelligent battery management: Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Automatic self tests insure battery reliability and warn customers in advance of battery replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down.
- Save time with easy and convenient remote/network accessibility: Network manageable via serial, USB or Ethernet. Includes Powerchute? Software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.
Protection
- Power conditioning: Protects connected loads from surges, spikes, lightning, and other power disturbances.
- Input Power Factor Correction: Minimizes installation costs by enabling the use of smaller generators and cabling.
- Resettable circuit breaker: Easy recovery from overloads; no need to replace a fuse. (Not available on Wall Tap SKUs)
- Safety-agency approved: Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
- Cold-start capable: Provides temporary battery power when the utility power is out.
- Generator compatible: Ensures clean, uninterrupted power to protected equipment when generator power is used.
- Frequency and voltage regulation: Gives higher application availability by correcting poor frequency and voltage conditions without using the battery.
TECHNICAL SPECIFICATIONS
Output
- Max Configurable Power (Watts): 10.0kWatts /10.0kVA
- Output Voltage Distortion: Less than 2 %
- Output Frequency (sync to mains): 50/60 Hz +/- 3 Hz Sync to mains
- Other Output Voltages: 220 V, 240 V
- Load Crest Factor: 3 : 1
- Topology: Double conversion online
- Waveform type: Sine wave
- Bypass: Internal bypass (automatic and manual)
Input
- Input frequency: 40 – 70 Hz Auto-sensing
- Input voltage range for main operations: 100 – 275 Adjustable (half load), 173 – 476 Adjustable (half load)V
- Other Input Voltages: 220V, 240 V, 380 V, 415 V
Batteries & Runtime
- Battery type: Lead-acid battery
- Typical recharge time: 1.5hour(s)
- Nominal Battery Voltage: +/- 192 V (split battery referenced to neutral)
- Replacement Battery: APCRBC140
- Expected Battery Life (years): 3 – 5
- RBC Quantity: 2
- Battery Charge Power (Watts): 1.195 kWatts
- Extendable Run Time: 1
- Runtime: View Runtime Graph
- Efficiency: View Efficiency Graph
Communications & Management
- Interface Port(s): RJ-45 10/100 Base-T, RJ-45 Serial, Smart-Slot, USB
- Control panel: Multifunction LCD status and control console
- Audible Alarm: Audible and visible alarms prioritised by severity
- Emergency Power Off (EPO): Yes
- Available SmartSlot™ Interface Quantity: 1
Surge Protection and Filtering
- Surge energy rating: 480Joules
Physical
- Maximum Height: 263MM, 26.3CM
- Maximum Width: 432MM, 43.2CM
- Maximum Depth: 715MM, 71.5CM
- Net Weight: 111.82 KG
- Shipping weight: 130.0 KG
- Shipping Height: 461MM, 46.1CM
- Shipping Width: 600MM, 60.0CM
- Shipping Depth: 1000MM, 100.0CM
- Color: Black
Environmental
- Operating Temperature: 0 – 40 °C
- Operating Relative Humidity: 0 – 95 (Non-condensing) %
- Operating Elevation: 0 – 3048meters
- Storage Temperature: -15 – 45 °C
- Storage Relative Humidity: 0 – 95 (Non-condensing) %
- Storage Elevation: 0 – 15240meters
- Audible noise at 1 meter from the surface of the unit: 55.0dBA
- Online thermal dissipation: 1947.0BTU/hr
- Protection Class: IP20
Conformance
- Approvals: CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE
- Standard warranty: 3 years repair or replace (excluding battery) and 2 years for battery
Sustainable Offer Status
- RoHS
-
Compliant
