General
|
 |
| UPS Topology |
Line-interactive |
| Energy Saving |
Yes |
|
|
Input
|
|
| Voltage |
220/230/240 Vac |
| Input Voltage Range |
170Vac – 290Vac |
| Input Frequency Range |
45-65Hz |
| Rated Input current |
3.86A |
| Plug Type |
AU |
| Plug Style |
Straight Angle |
| Cord Length (ft.) |
5 |
| Cord Length (m) |
1.5 |
|
|
Output
|
|
| VA |
850 |
| Watts |
510 |
| On Battery Waveform |
Simulated Sine Wave |
| On Battery Voltage |
220-240Vac |
| Automatic Voltage Regulation (AVR) |
Single Boost / Single Buck |
| Automatic Voltage Regulation (Line Mode) |
Boost Mode Voltage: Vinx1.18Buck Mode Voltage: Vinx0.85 |
| On Battery Frequency |
50/60Hz ? 1% |
| Overload Protection |
On Utility: Circuit Breaker & Inter’N/Al circuitry limiting / On Battery: Inter’N/Al Current Limiting |
| Outlets – Total |
8 |
| Outlet Type |
AU |
| Outlets – Battery & Surge Protected |
4 |
| Outlets – Surge-Only Protected |
4 |
| USB Charging Ports |
Yes |
| Rated Power Factor |
0.6 |
| Transfer Time |
4ms |
|
|
Battery
|
|
| Runtime at Half Load (min) |
8 |
| Runtime at Full Load (min) |
1 |
| Battery Type |
Sealed Lead Acid |
| Battery Number |
LEOCH/DJW12-9 |
| Battery Size |
12V/9AH |
| Battery Quantity |
1 |
| User Replaceable |
Yes |
| Hot-Swappable |
Yes |
| Typical Recharge Time |
8 Hours |
| Replacement Battery Pack |
RBP0006 |
| Replacement Battery Pack Quantity |
1 |
|
|
Surge Protection & Filtering
|
|
| Surge Suppression |
125 Joules (L-N) |
| Phone / Network Protection RJ11/RJ45 |
1-In, 1-Out (Combo) |
|
|
Management & Communications
|
|
| LCD Control Panel |
Yes |
| Multifunction LCD Diagnostic Display |
Battery Capacity, Load Capacity, Estimated run time, Input voltage, Output voltage, Line mode Icon, Battery mode Icon, Overloaded Icon, Silent mode Icon, Fault Icon |
| HID Compliant USB Port |
Yes |
| Management Cable |
USB&Phone Cable |
| LED Indicators |
YES |
| Audible Alarms |
On Battery, Low Battery, Overload, Fault |
| Software |
PowerPanel? Personal Edition |
|
|
Physical
|
|
| Form Factor |
Brick |
| Enclosure Construction |
Plastic |
| Mounting Hardware |
Yes |
|
|
Physical – UPS Module
|
|
| Dimensions (WxHxD) (mm.) |
166x118x288 |
| Weight (kg.) |
6.5 |
|
|
Environmental
|
|
| Operating Temperature |
32?F to 104? F / 0? C to 40? C |
| Operating Humidity |
0% – 90% non-condensing |
| Operating Elevation |
0-10000?feet (0-3000meters) |
| Storage Temperature |
– 4?F to 122? F / -20? C to 50? C |
| Storage Relative Humidity |
0% – 90% |
| Storage Elevation |
0-3000 meters |
| Online Thermal Dissipation |
72 BTU/hr |
| Audible noise at 1.5M from surface of unit |
<40dB |
|
|
Certifications
|
|
| Certifications |
CE/RCM |
| RoHS |
RoHS Compliant |
|
|
Warranty
|
|
| Product Warranty |
2 Years Advanced Replacement |
| Connected Equipment Guarantee |
Lifetime |
| CEG Amount |
75000 AUD |
|
|
