Features & Benefits:
- 2RU Rack Space
- Pure Sinewave Output
- Online (Double Conversion) UPS Topology
- 3 Year On-UPS and 2 Year On-Internal Battery Advanced Replacement Warranty, Australia-wide
- Rack or Tower Convertible Configurations
- EMI, RFI, Surge and Lightning Spike Protection
- Critical Load Outlets
- Phone/Fax/Modem/DSL/Network Protection
- Auto-Restart/Auto-Charge
- Emergency Power Off (EPO) Port
- Multifunction LCD Readout
- Rotatable LCD Indicator
- USB & Serial Connectivity Port
- Extended Runtime (XL) Models
- Hot-Swappable Battery Packs
- Dual Input
- Smart Fan Speed Control By Load Level
- Economy Mode Setting
- Smart Battery Management(SBM)
- Remote Control/Wall-Mountable LCD Panel
- Generator Mode setting
- SNMP/HTTP Remote Management Capability (Optional)
- PowerPanel Business Edition Software
| Model | OL2000ERTXL2U |
| Capacity(VA/W) | 2000VA / 1800W |
| Typology | Online (Double Conversion) |
| Form Factor | Rackmount / Tower (Convertible) |
| Energy-Saving Technology | Yes, ECO Mode Efficiency: 93% |
| Input | |
| Voltage Range | 120~139Vac for 0~25% Load 140~159Vac for 0~50% Load 160~179Vac for 0~75% Load 180~280Vac for 0~100% Load |
| Frequency Range | 40~70Hz |
| Input Plug Type | IEC C14 |
| Output | |
| Voltage Range | Pure sine wave at 200, 208, 220, 230, 240Vac (Configurable) 2% |
| Frequency Range | 50 / 60Hz (Auto-Sensing or Configurable) 0.25Hz |
| Transfer Time (Typical) | 0ms |
| Overload Protection | Line Mode 105~125% Load for 1 min, 126~150% Load for 10 sec Battery Mode 105~130% Load for 10 sec, 131~150% Load for 2 sec |
| Short Circuit Protection | UPS Output Cut Off Immediately |
| Surge Protection and Filtering | |
| Lightning / Surge Protection | Yes |
| DSL/Phone/Fax/Modem protection | RJ11/RJ45(One In/One Out) |
| Physical | |
| Receptacles | (8) IEC C13, (1) IEC C19 |
| Dimensions(H x W x D)(mm) | 88x433x600 |
| Weight(kg) | 31 |
| Battery | |
| Sealed Maintenance Free Lead Acid Battery | 12V / 9AH x 6 |
| Hot-Swappable | Yes |
| Typical Recharge Time | 4 Hours |
| Runtimes | |
| Half load-Full load (mins) | 17/6 |
| Status Indication | |
| Indicators | Power On, Line Mode, Battery Mode, Bypass Mode, Fault, Replace Battery |
| Audible Alarms | Battery Mode, Battery Low, Overload, UPS Fault, Replace Battery |
| Multi-Function LCD Readout | Yes |
| Communication | |
| Power Management Software | PowerPanel Business Edition |
| Management | |
| Self-Test | Yes |
| Auto-Charge/Auto-Restart | Yes |
| Auto-Overload Recovery | Yes |
| Cold Start(DC Start) | Yes |
| COM Interface | (1) Serial Port (RS232), (1) USB Port, (1) Relay Out, (1) EPO |
| SNMP/HTTP Capable | Optional |
