A lockable benchtop cabinet that charges and stores 16 phones or tablets at once. Each port delivers 5V / 2A — 10 watts — which suits phones and tablets up to 10.1 inches. It is not enough to charge a laptop or a modern Chromebook; for those, see the 30 Bay AC model. The 16 Bay sits on feet rather than castors, so it is built to stay put on a bench or counter.
Specification
- Model – UPT-CHARGE16-USB
- Name – USB charging cart
- Capacity – 16 USB charging ports
- Overall size (W*D*H) – W520 x D410 x H350 (mm)
- Packing size (W*D*H) – W560 x D455 x H385 (mm)
- Device slots – W23 x H230 x D310 (mm)
- Suitable size of devices – up to 10.1 inch
- Applicability – Tablet / Phone / USB devices
- Net weight – 13kg
- Gross weight – 18.5kg
- Main material – SPCC + ABS
- Input – 110V, 13A, 60Hz or 220V, 10A, 50Hz
- Output – 5.0V, 2.0A (USB port x16)
- Equipped power – 400W
- Maximum output power – 160W
Device slot measurements are the internal slot, not the cabinet. Measure your device in the case it lives in — 23mm leaves room for a slim folio, not a rugged case.
Safety Protection
- Overvoltage protection – Support
- Grounding protection – Support
- Overload protection – Support
- Overcurrent protection – Support
- Short-circuit protection – Support
- Surge protection – Support
- Leakage protection – Support
- Isolation protection – Support
Facade Features
- Curved cabinet shape – Support
- 120 degree door – x2
- Castors – Not fitted (benchtop model, sits on feet)
- Door lock – x1
- Fan – x1
- Recessed power cord storage – Not fitted
- Circuit breaker – x1
- Flame-retardant divider (V0) – x17
- Power supply – x1
- LED indicator – x16, red: charging / green: fully charged
Data Transmission – Support
- Universal for USB interface devices — charges and syncs data at the same time
- Supports data transfer between a host computer and a connected tablet
- Complies with the USB 2.0 protocol, backward compatible
- High-speed, full-speed and low-speed devices all supported
Australian Compliance
- RCM marked — Declaration of RCM Compliance RCM-2023VT1208300RCMV00, covering all three models in the range (UPT-CHARGE16-USB, UPT-CHARGE30-AC, UPT-CHARGE48-USB)
- Electrical safety — tested to AS/NZS 62368.1:2022, including the Australian national deviations. Pass. Report LGT23J021SA01, 31 October 2023
- Electromagnetic compatibility — tested to AS/NZS CISPR 32:2015 + A1:2020, Class B (conducted and radiated emissions). Pass. Report LGT23J021EM01, 23 October 2023
- Registered under the Electrical Equipment Safety System (EESS) as Level 1 equipment, current to 12 August 2028
- Testing laboratory — Shenzhen LGT Test Service Co., Ltd (A2LA accreditation 6727.01)
RCM is a supplier declaration of compliance, not a government approval. Procurement officers can quote the declaration number above.
Other certification – CE, FCC, RoHS, REACH, CA65, CCC, safety inspection report
Operating Environment
- Working environment temperature – 0 ℃ ~ 45 ℃
- Working environment humidity – 20% ~ 80%
- Storage environment temperature – 0 ℃ ~ 45 ℃
Packing List
- Charging cart – x1
- Door key – x2
- Power cord – x1
- USB charging cable – x16
- User manual – x1
- QC certificate – x1
Capacity Container
- 20GP – 255 pieces
- 40HQ – 630 pieces
Warranty
- 12 months full replacement warranty
