Technical Specification
MODEL RTX3000LCD
- CAPACITY – 3000VA/2700W
INPUT
- Nominal Voltage – 220/230(Default)/240Vac
- Voltage – 161~276 VAC
- Voltage Range – 50/60Hz ±5Hz for Normal Mode
OUTPUT
- Nominal Voltage – 220/230(Default)/240Vac
- Voltage Regulation – +/- 5% (Battery mode)
- Frequency Range – 50/60Hz
- Frequency Regulation – ±0.1Hz (Battery mode)
- Waveform – Pure sine wave
TRANSFER TIME
- Battery <-> Line – Typical 2-6 ms
BATTERY
- Type (Lead-acid) – 12V/9Ah*6
PHYSICAL
- Dimension (D*W*H) – 608mm*438mm*86.5 mm
- Net weight – 31kg
ENVIRONMENT
- Operating Environment – 0° to 40° C
- Noise Level (Less than) – 45dB
