Features & Benefits:
- 1RU rack space
- Green Power UPS™ Technology: Energy-Saving UPS
- Save up to 75% on electricity costs compared to competing brands
- 3 Year on UPS and 2 Year on Internal Batteries Advanced Replacement Warranty Australia Wide
- Pure Sine Wave output
- Line-interactive technology
- Automatic Voltage Regulator (AVR)
- PowerPanel Business Edition software
- Multiple outputs for multiple servers
- Multiple communication interfaces
- Programmable brownout and overvoltage protection
- Microprocessor-based full digital control
- EMI, RFI, Surge, and spike protection
- Scheduled shutdown
- Auto restart/Auto charge
- User-replaceable batteries
- SNMP / HTTP Remote Management Capabilities (optional) Refer to RMCARD203
- Critical load outlets
- Metal housing
- Multifunction LCD readout
- Audible alarms
- Resettable Circuit Breaker
- Hot-swappable battery packs
- Emergency Power-Off (EPO) Port
- Protected On/Off Switch
- Equipment Protection Policy up to 50,000 AUD
Package Contents:
- UPS unit
- User manual
- PowerPanel? Business Edition software CD
- Rack mount Brackets
- Phone line
- USB A B type cable
- Emergency Power-Off Cable (gray)
- Serial Interface Cable (DB-9)
- Power Cord x 4
| Model | PR1000ELCDRT1U |
| Capacity (VA/Watts) | 1000VA / 670W |
| Energy-Saving Technology | Yes |
| Input | |
| Voltage Range(Adjustable) | 150Vac – 300Vac |
| Frequency Range | 50Hz / 60 Hz /- 3Hz (auto sensing) |
| Input Plug Type | IEC 320 C14 |
| Output | |
| UPS Outlets | (6) IEC 320 C13 |
| On Battery Output Voltage | Pure Sine Wave at 230Vac /- 5% |
| On Battery Output Frequency | 50Hz / 60 Hz /- 0.1Hz |
| Transfer Time (Typical) | 4ms |
| Overload Protection | Internal Current Limiting/Circuit Breaker |
| AVR | Buck/ Boost/ Double Boost |
| Surge Protection and Filtering | |
| Surge Protection | Yes |
| DSL/Phone/Fax/Modem protection | – |
| Physical | |
| Maximum Dimensions(H x W x D)(mm) | 44 x 433 x 490 |
| Weight(kg) | 18 |
| Battery | |
| Sealed Maintenance Free Lead Acid Battery | 6V 9AH x 4 |
| User Replaceable | Yes |
| Typical Recharge Time | 6 Hours |
| Runtimes | |
| Half-Load/ Full-Load(mins) | 14/5 |
| Status Indication | |
| Indicators | Power On, Using Battery, AVR, Load Level, Battery Level |
| Audible Alarms | On Battery, Low Battery, Overload |
| Multi-Function LCD Readout | Yes |
| Communication | |
| Power Management Software | PowerPanel Business Edition |
| Management | |
| Self-Test | Yes |
| Auto-Charge/Auto-Restart | Yes |
| COM Interface | Yes |
| USB Interface | Yes |
| SNMP/HTTP Capable | Yes |
